Implementación de un sistema de coordenadas con las propiedades de zoom y pan
Ya sea para encontrar la ubicación aproximada en un mapa geográfico o las coordenadas de unos píxeles en una imagen, necesitamos un sistema de referencia. Rene Descartes inventó el plano cartesiano, que en 2 dimensiones se representa mediante dos líneas perpendiculares entre sí cuyo eje vertical y horizontal interseccionan en el punto 0,0.
Para crear este sistema de coordenadas utilizando JavaScript y la API Canvas de HTML, podríamos empezar dibujando los ejes: escribiríamos un bucle para trazar lineas horizontales y otro para las verticales usando la instrucción ctx.lineTo(x, y)
. Y luego podríamos añadir la funcionalidad de movernos por el plano mediante eventos del ratón, guardando la posición inicial al primer clic y después al soltar haríamos la traslación de las lineas del plano restando la diferencia de la posición actual con la guardada anteriormente para simular el efecto de “arrastrar” los objetos.
Pero si aun quisieramos complicarlo más, bastaría con añadirle la opción de poder aumentar o disminuir la escala del plano de forma infinita.
En este artículo haremos todo lo anterior. Explicaremos qué herramientas matemáticas se necesitan y proporcionaremos el código para generar un sistema de coordenadas 2d usando JavaScript.
Si quieres ver directamete el código en acción, aquí puedes ver el resultado final del sistema de coordenadas en 2d:
<!doctype html><html lang="en"> <head> <meta charset="UTF-8" /> <meta name="viewport" content="width=device-width, initial-scale=1.0" /> <title>Sistema de coordenadas en un plano 2d infinito con JavaScript</title> <style></style> </head>
<body> <p> Utiliza el ratón para moverte sobre el plano y la rueda para ampliar/disminuir el zoom. </p>
<script type="text/javascript"> function Matrix(entries) { this.entries = entries this.rows = this.entries.length this.cols = this.entries[0].length
this.multiply = function (a) { let new_entries = []
for (let i = 0; i < this.rows; i++) { new_entries.push([]) for (let j = 0; j < a.cols; j++) { new_entries[i].push(0) for (let k = 0; k < this.cols; k++) { new_entries[i][j] += this.entries[i][k] * a.entries[k][j] } } }
return new Matrix(new_entries) }
this.add = function (a) { if (this.cols !== a.cols || this.rows !== a.rows) { throw 'Incompatible sizes' }
let new_entries = []
for (let i = 0; i < this.rows; i++) { new_entries.push([]) for (let j = 0; j < a.cols; j++) { new_entries[i].push(this.entries[i][j] + a.entries[i][j]) } }
return new Matrix(new_entries) }
this.scale = function (k) { let new_entries = []
for (let i = 0; i < this.rows; i++) { new_entries.push([]) for (let j = 0; j < this.cols; j++) { new_entries[i].push(k * this.entries[i][j]) } } return new Matrix(new_entries) }
this.subtract = function (a) { return this.add(a.scale(-1)) }
this.entry = function (i, j) { return this.entries[i][j] }
this.determinant = function () { return ( this.entries[0][0] * this.entries[1][1] - this.entries[0][1] * this.entries[1][0] ) }
this.inverse = function () { if (this.cols !== 2 || this.rows !== 2) { throw 'Incompatible size' }
let det = this.determinant() if (det === 0) { throw 'Matrix is not invertible' }
let new_entries = [ [this.entries[1][1], -this.entries[0][1]], [-this.entries[1][0], this.entries[0][0]], ]
return new Matrix(new_entries).scale(1 / det) }
this.toString = function () { let o = '' for (let i = 0; i < this.rows; i++) { for (let j = 0; j < this.cols; j++) { o += this.entries[i][j] + ' ' }
if (i + 1 < this.rows) { o += '\n' } } return o } }
class CoordinateSystem { constructor(canvas) { this.canvas = canvas this.context = this.canvas.getContext('2d') this.settings = { gridLines: { major: { spacing: 1, color: '#555', width: 0.5, }, minor: { spacing: 0.25, color: '#777', width: 0.25, }, }, backgroundColor: 'white', axes: { color: 'black', width: 2, labelColor: 'black', }, border: { color: 'black', width: 5, }, }
this.zoomLevel = 1 this.zoomMatrix = new Matrix([ [100, 0], [0, 100], ]) this.translation = new Matrix([[1], [1]])
const mouseState = { pressed: false, prevPosistion: null, }
this.canvas.addEventListener('mousedown', e => { mouseState.pressed = true })
this.canvas.addEventListener('mouseup', e => { mouseState.pressed = false })
this.canvas.addEventListener('mouseleave', e => { mouseState.pressed = false })
this.canvas.addEventListener('mousemove', e => { const x = e.offsetX const y = e.offsetY
if (mouseState.pressed && mouseState.prevPosistion) { const currentPosition = this.fromCanvasCoords(x, y) const prevPosistion = this.fromCanvasCoords( mouseState.prevPosistion[0], mouseState.prevPosistion[1] )
this.translate( currentPosition[0] - prevPosistion[0], currentPosition[1] - prevPosistion[1] ) } mouseState.prevPosistion = [x, y] })
this.canvas.addEventListener('mousewheel', e => { e.preventDefault() const x = e.offsetX const y = e.offsetY const zoomFactor = 0.001 * e.wheelDelta this.zoom(zoomFactor, x, y) })
this.draw() }
drawGridlines() { this.context.beginPath() const topLeft = this.fromCanvasCoords(0, 0) const bottomRight = this.fromCanvasCoords( this.canvas.width, this.canvas.height )
for (const i in this.settings.gridLines) { this.context.strokeStyle = this.settings.gridLines[i].color this.context.lineWidth = this.settings.gridLines[i].width
const spacing = this.settings.gridLines[i].spacing
let startX = spacing * Math.ceil(topLeft[0] / spacing) let endX = spacing * Math.floor(bottomRight[0] / spacing)
this.context.beginPath()
for (let x = startX; x <= endX; x += spacing) { const coords = this.canvasCoords(x, 0)
this.context.moveTo(coords[0], 0) this.context.lineTo(coords[0], this.canvas.height) }
let endY = spacing * Math.ceil(topLeft[1] / spacing) let startY = spacing * Math.floor(bottomRight[1] / spacing)
for (let y = startY; y <= endY; y += spacing) { const coords = this.canvasCoords(0, y) this.context.moveTo(0, coords[1]) this.context.lineTo(this.canvas.width, coords[1]) }
this.context.stroke() } }
drawAxes() { const origin = this.canvasCoords(0, 0) const x = origin[0] const y = origin[1]
if ( (x >= 0 && x <= this.canvas.width) || (y >= 0 && y <= this.canvas.height) ) { this.context.beginPath() this.context.strokeStyle = this.settings.axes.color this.context.lineWidth = this.settings.axes.width this.context.moveTo(0, y) this.context.lineTo(this.canvas.width, y) this.context.moveTo(x, 0) this.context.lineTo(x, this.canvas.height) this.context.stroke() } }
drawTickLabels() { this.context.fillStyle = this.settings.axes.labelColor this.context.font = '12px Arial' this.context.textAlign = 'center' this.context.textBaseline = 'middle'
const topLeft = this.fromCanvasCoords(0, 0) const bottomRight = this.fromCanvasCoords( this.canvas.width, this.canvas.height )
const spacing = this.settings.gridLines.major.spacing
let startX = spacing * Math.ceil(topLeft[0] / spacing) let endX = spacing * Math.floor(bottomRight[0] / spacing)
for (let x = startX; x <= endX; x += spacing) { const coords = this.canvasCoords(x, 0) this.context.fillText( this.formatLabel(x), coords[0], coords[1] - 10 ) }
let endY = spacing * Math.ceil(topLeft[1] / spacing) let startY = spacing * Math.floor(bottomRight[1] / spacing)
for (let y = startY; y <= endY; y += spacing) { const coords = this.canvasCoords(0, y) this.context.fillText( this.formatLabel(y), coords[0] + 10, coords[1] ) } }
formatLabel(num) { if (Math.abs(num) > 100000) { return num.toExponential(2) } else if (Number.isInteger(num)) { return num.toString() } else if (Math.abs(num) < 0.001) { return num.toExponential(2) } else { return num.toFixed(3) } }
draw() { this.context.fillStyle = this.settings.backgroundColor this.context.fillRect(0, 0, this.canvas.width, this.canvas.height) this.context.strokeStyle = this.settings.border.color this.context.lineWidth = this.settings.border.width this.context.strokeRect(0, 0, this.canvas.width, this.canvas.height) this.drawGridlines() this.drawAxes() this.drawTickLabels() }
canvasCoords(x, y) { const point = new Matrix([[x], [y]]) const newPoint = this.zoomMatrix.multiply(point).add(this.translation)
const coords = [newPoint.entry(0, 0), newPoint.entry(1, 0)]
return [ coords[0] + 0.5 * this.canvas.width, -coords[1] + 0.5 * this.canvas.height, ] }
fromCanvasCoords(x, y) { x -= 0.5 * this.canvas.width y = -(y - 0.5 * this.canvas.height)
const point = new Matrix([[x], [y]]) const newPoint = this.zoomMatrix .inverse() .multiply(point.subtract(this.translation)) return [newPoint.entry(0, 0), newPoint.entry(1, 0)] }
translate(u, v) { const w = new Matrix([[u], [v]]) const vector = this.zoomMatrix.multiply(w) this.translation = this.translation.add(vector) this.draw() }
zoom(zoomFactor, mouseX, mouseY) { const worldCoords = this.fromCanvasCoords(mouseX, mouseY) const worldCoordsMatrix = new Matrix([ [worldCoords[0]], [worldCoords[1]], ]) const newZoom = this.zoomMatrix.scale(zoomFactor + 1)
const zoomDifference = newZoom.subtract(this.zoomMatrix)
this.translation = this.translation.subtract( zoomDifference.multiply(worldCoordsMatrix) ) this.zoomMatrix = newZoom
this.zoomLevel *= zoomFactor + 1 if (this.zoomLevel >= 2 || this.zoomLevel <= 0.5) { const factor = this.zoomLevel >= 2 ? 0.5 : 2
for (const i in this.settings.gridLines) { this.settings.gridLines[i].spacing *= factor }
this.zoomLevel *= factor }
this.draw() } }
const canvas = document.createElement('canvas') canvas.width = 1000 canvas.height = 600 const grid = new CoordinateSystem(canvas) document.body.appendChild(canvas) </script> </body></html>
Lo primero es crear el elemento canvas y añadirlo dentro del elemento <body>
const canvas = document.createElement('canvas')canvas.width = 1000canvas.height = 600document.body.appendChild(canvas)
Para iniciar la aplicación crearemos una nueva instancia de la clase CoordinateSystem pasándole el elemento canva como parámetro:
new CoordinateSystem(canvas)
Puedes ver el código completo en el ejemplo anterior. Aquí sólo comentaremos los puntos más importantes.
Para dibujar la cuadrícula de lineas, lo haremos en el método drawGridLines()
. Dibujaremos unas lineas más gruesas y otras más finas:
drawGridlines() { this.context.beginPath(); const topLeft = this.fromCanvasCoords(0, 0); const bottomRight = this.fromCanvasCoords( this.canvas.width, this.canvas.height );
for (const i in this.settings.gridLines) { this.context.strokeStyle = this.settings.gridLines[i].color; this.context.lineWidth = this.settings.gridLines[i].width;
const spacing = this.settings.gridLines[i].spacing;
let startX = spacing * Math.ceil(topLeft[0] / spacing); let endX = spacing * Math.floor(bottomRight[0] / spacing);
this.context.beginPath();
for (let x = startX; x <= endX; x += spacing) { const coords = this.canvasCoords(x, 0);
this.context.moveTo(coords[0], 0); this.context.lineTo(coords[0], this.canvas.height); }
let endY = spacing * Math.ceil(topLeft[1] / spacing); let startY = spacing * Math.floor(bottomRight[1] / spacing);
for (let y = startY; y <= endY; y += spacing) { const coords = this.canvasCoords(0, y); this.context.moveTo(0, coords[1]); this.context.lineTo(this.canvas.width, coords[1]); }
this.context.stroke(); }}
Para dibujar los ejes x e y, usaremos el método drawAxes
. Obtendremos el origen 0,0 como punto de referencia y luego trazaremos primero la linea horizontal y luego la vertical.
drawAxes() { const origin = this.canvasCoords(0, 0); const x = origin[0]; const y = origin[1];
if ( (x >= 0 && x <= this.canvas.width) || (y >= 0 && y <= this.canvas.height) ) { this.context.beginPath(); this.context.strokeStyle = this.settings.axes.color; this.context.lineWidth = this.settings.axes.width; this.context.moveTo(0, y); this.context.lineTo(this.canvas.width, y); this.context.moveTo(x, 0); this.context.lineTo(x, this.canvas.height); this.context.stroke(); }}
Hay dos métodos básicos que son clave para gestionar la visualización del gráfico, estos son canvasCoords
que convierte cualquier posición x e y a la posición que tiene dentro del canvas y fromCanvasCoords
que hace justo lo contrario, a partir de unas coordenadas del canvas nos devuelve la posición x e y reales.
canvasCoords(x, y) { const point = new Matrix([[x], [y]]); const newPoint = this.zoomMatrix.multiply(point).add(this.translation);
const coords = [newPoint.entry(0, 0), newPoint.entry(1, 0)];
return [ coords[0] + 0.5 * this.canvas.width, -coords[1] + 0.5 * this.canvas.height, ];}
fromCanvasCoords(x, y) { x -= 0.5 * this.canvas.width; y = -(y - 0.5 * this.canvas.height);
const point = new Matrix([[x], [y]]); const newPoint = this.zoomMatrix .inverse() .multiply(point.subtract(this.translation)); return [newPoint.entry(0, 0), newPoint.entry(1, 0)];}
Como ves, ambos métodos utilizan operaciones matemáticas con matrices para aplicar traslaciones de las coordenadas. Mira detallademente el código de la función Matrix
en el código de ejemplo para ver los métodos implementados para operar con matrices.
Lo que en inglés se conoce como pan & zoom. Gestionaremos la traslación con el método translate
que llamaremos desde el evento mousemove (cuando el ratón esté pulsado y en movimiento) para generar el efecto de mover el gráfico. Y algo parecido conn el método zoom
.
translate(u, v) { const w = new Matrix([[u], [v]]); const vector = this.zoomMatrix.multiply(w); this.translation = this.translation.add(vector); this.draw();}
zoom(zoomFactor, mouseX, mouseY) { const worldCoords = this.fromCanvasCoords(mouseX, mouseY); const worldCoordsMatrix = new Matrix([[worldCoords[0]], [worldCoords[1]]]); const newZoom = this.zoomMatrix.scale(zoomFactor + 1);
const zoomDifference = newZoom.subtract(this.zoomMatrix);
this.translation = this.translation.subtract( zoomDifference.multiply(worldCoordsMatrix) ); this.zoomMatrix = newZoom;
this.zoomLevel *= zoomFactor + 1; if (this.zoomLevel >= 2 || this.zoomLevel <= 0.5) { const factor = this.zoomLevel >= 2 ? 0.5 : 2;
for (const i in this.settings.gridLines) { this.settings.gridLines[i].spacing *= factor; }
this.zoomLevel *= factor; }
this.draw();}
Este código es sólo un ejemplo de cómo implementar un sistema de coordenadas, pero si quieres ampliarlo te propongo varias mejoras:
